QUALITY SPECIFICATIONS
JUNE V.4 2021
FOUNDATION
• Reinforced concrete foundation with tie beams.
• Concrete slab according to typology.
STRUCTURE
According to the details of the project structure:
• Reinforced concrete, one-way slab.
• Reinforced concrete waffle slab with steel/concrete pillars and beams.
ROOF
• Inverted flat roof with double waterproofing layer and high-density insulation protected with gravel in no
transitable areas and finished with ceramic tiles on terraces.
EXTERIOR WALLS AND SURFACE
• Exterior face consisting of two layers: exterior layer, made of ceramic brick with insulation of projected
polyurethane or similar, interior face finished with double laminated gypsum board and mineral wool
insulation.
• Exterior renders with damp proof cement mortar and/or natural stone cladding according to the building type.
INTERIOR WALLS AND SURFACES
• Interior divisions of the house with self-supporting framing partitions and laminated gypsum boards
(13+13mm in both sides), including insulation of mineral wool or similar. Plastic paint, color to be
defined by DF.
FLOOR TILES
• Ceramic porcelain 90x90cm.
WALL TILES
• Floor to ceiling Ceramic, according to Project specificactions.
KITCHEN
• Fully equipped with Siemens appliances.
• Ceramic work surface, according to the building type.
EXTERIOR CARPENTRY
• Aluminum carpentry, profiles by Cortizo or similar.
• Sliding doors and Windows with thermal break and double glazing according to Project specificactions.
INTERIOR CARPENTRY
• Front door: Pivot security system, Iroko finish.
• Interior doors: White smooth lacquered wood with concealed hinges.
• Wardrobes: White lacquered wood.
GARDENS AND DIVISIONS
• Division with galvanized mesh and/or “vegetation screen” according to type and location.
• Finished gardens equipped with automated irrigation systems.
• Retaining walls between plots with exposed reinforced concrete or stone, according to the specifications of
the design.
SWIMMING POOL
• Reinforced concrete structure, waterproofed.
• Sukabumi colour porcelain tilling – 60x30cm – and pool perimeter with non-slip ceramic surround.
SANITATION
• System separating rainwater and wastewater.
ELECTRICITY
• Electrical switches and sockets JUNG or similar
HEATING AND AIR CONDITIONING
• VRV Direct Expansion Air Conditioner, Concealed Duct Cooling with independent control per stay.
• Underfloor heating by water using an aerothermal system throughout the living place; In bathrooms, electric
underfloor heating will be installed, each room with independent control.
SANITARY WARE AND TAPS
• Bathroom fittings by Villeroy & Boch and taps by Grohe or another leading brand.
OTHER EQUIPMENT
• Fermax Smile video entry system or similar.
• Preinstallation for a charging point at the parking space
